Product Information
Process time (Aligner cut): approx. 60-90s
Aligner foils diameter: ø120-125mm
Aligner foils height: 0,25-1mm
Repeat accuracy: ±0,1mm
Laser
Laser type: CO2
Laser power: 20W
Wavelength: 9,3μm
Laser class of product: Class 1
Cooling: Air-cooled
Power
Voltage: Single-phase, 110-230, 50/60Hz
Power consumption: 900W
Interfaces
Hardware Interface: Gigabit Ethernet (IEEE 802.3)
Software Interface: Import of universal aligner data (model as STL and trim line as PTS, CSV or XYZ file)
Suction Unit (requirements)
Connection diameter: ø50mm
Air flow rate (unimpeded): 240m3/h
Filter • Prefilter mat G4, • HEPA filter H13, • Activated carbon
General
W / L / H (opened): 620x880x640mm (980mm)
Weight: 78kg | 171.9Lbs.
Noise level: 65db(A)
3DNA Dental Blog Post:
Transforming Clear Aligner Production with the Laser Aligner Cutter System
LAC also offers digital interfaces to the best suppliers such as Dental Axess (Xflow/Xplan) and ArcadLab; data compatibility to all major vendors like 3Shape, OnyxCeph or ORTH’UP”.
